Gr A/B ASTM A588 Corten Steel Plate China Supplier For Outdoor Decoration
Category:
Product Details
Installation Steps:
Corten Steel Plate is widely used in landscape decoration, building curtain walls, and other fields due to its unique rust appearance and superior weather resistance. During the installation process, it is necessary to strictly follow the standard steps and pay attention to relevant matters to ensure its beauty and service life.
1. Installation steps:
Basic preparation: Before installation, it is necessary to ensure that the basic structure is flat, firm, and free of impurities. If used for facades or decorative walls, fixings or angle steels should be embedded in advance.
2. Lofting and positioning: Lofting is carried out accurately according to the design drawings, and the installation position of the steel plate is marked to ensure neat arrangement and uniform gaps.
3. Plate processing: Cut the steel plate according to the size of the drawing, and grind the edges and corners to avoid sharp edges affecting construction and safety. If the plate is not pre-rusted, the surface can be degreased and rusted first to facilitate the subsequent uniform formation of the rust layer.
4. Installation in place: Use bolts, welding or special clamps to fix the steel plate to the structure to ensure a firm installation. If welding is used, special welding wire for weathering steel must be used, and the heat-affected zone must be controlled to avoid affecting the appearance.
5. Rust layer treatment (optional): After installation, artificial rust treatment can be carried out, such as spraying acidic rust-inducing liquid, to promote the rapid and uniform formation of a rust layer on the surface and improve the decorative effect.
|
Chemical composition
|
|||||||||
|
ASTM SA515
|
C
|
C
|
C
|
C
|
C
|
Mn
|
P
|
S
|
Si
|
|
Thk (mm)
|
t≤25
|
25-50
|
50-100
|
100-200
|
>200
|
Max
|
Max
|
Max
|
|
|
A515 Gr 60
|
0.24
|
0.27
|
0.29
|
0.31
|
0.31
|
0.98
|
0.025
|
0.025
|
0.13-0.45
|
|
A515 Gr 65
|
0.28
|
0.31
|
0.33
|
0.33
|
0.33
|
0.98
|
0.025
|
0.025
|
0.13-0.45
|
|
A515 Gr 70
|
0.31
|
0.33
|
0.35
|
0.35
|
0.35
|
1.30
|
0.025
|
0.025
|
0.13-0.45
|
Precautions:
Reserve expansion joints: Weathering steel is greatly affected by thermal expansion and contraction. Appropriate expansion joints should be reserved during installation to prevent deformation.
Avoid long-term water accumulation: Ensure smooth drainage to avoid rainwater accumulation on the surface of the steel plate, otherwise it may cause local rust to intensify.
Rust water treatment: Rust water will flow out in the initial rust stage, and pollution of surrounding walls or ground should be avoided. If necessary, a diversion system can be set up.
Isolation from other metals: Avoid direct contact with metals such as stainless steel and aluminum to prevent electrochemical corrosion.
Maintenance inspection: Regularly check the stability of the rust layer. If uneven rust or peeling is found, it should be treated in time to maintain the overall effect.
Through scientific installation and reasonable maintenance, Corten Steel Plate can not only show unique natural beauty, but also maintain good performance for a long time in harsh environments.
Please click on www.teda-metal.com for more products about stainless steel
|
Material |
ASTM standard: Corten A, Corten B, A588 Gr A/B/C/D, ASTM A242;
JIS standard: SPA-H, SPA-C,
GB standard: 09CuCrPNi-A, B480GNQR, Q235NH, Q295NH, Q355NH, Q460NH, Q295GNH, Q295GNHL,Q345GNH, Q345GNHL,Q390GNH.
EN standard: S355J0W, S355J0WP, S355J2W, S355J2WP, etc.
|
|
Origin Mill |
Baosteel, Ansteel, Masteel,etc |
|
Thickness |
Cold rolled: 0.5mm, 0.6mm, 0.7mm, 0.8mm, 0.9mm, 1.0mm,1.2mm; Hot rolled: 1.6,2.0,2.5,3.0,4,5,6,8,10,12,14,16,20,25...40mm |
|
Common width |
1116mm, 1175mm, 1180mm, 1200mm, 1230mm, 1250mm, 1500mm, 1800mm, 2000mm, etc |
|
Length |
Cut to any length |
Application
Corten steels are typically used in Railway, bridges, rolling stock, shipping container, Garden building, and other structural applications.
